工业门户的水和防尘外壳

Water and dust proof enclosure for Industrial IoT Gateway

TheWater and Dust proof enclosurehas been designed to protect theIIoT Gateway（型号1111）在室外或工业室内条件下。机箱包括网关AC/DC power supply,DC cable和网关持有人. Class II design (no FG pin).

环境条件

• Ambient temperature -20-50 °C
• 储存温度-40-85°C
• Relative humidity 20-90 %,
• noncondensing
• Flammability rating: UL 746C

机械规格

• 外壳保护等级IP67
• Size 175 x 175 x 75mm, excl. cable glands
• Pressure equalizer plug
• 壁挂式安装
• Impact strength: IK08
• Color: grey RAL-7035
• Material: Base Fiberglass-reinforced PC
• Cover transparent PC plastic.

电源：

• 电压范围85-264Vac.
• Frequency Range 47-440Hz
• Power Consumption 30VA Max
• 电气连接变体：
  • EURO TYPE F UNGROUNDED 2 WIRE
  • NEMA 1-15 II类电源线安全和EMC
  • Safety UL60950-1, TUV EN60950-1
  • EMC免疫EN61000 1,2,3,5,6,8,11
  • Surge L-N 1kV
